1/2-Inch Air-Operated Double Diaphragm (AODD) Pump
Discover our air-operated double diaphragm pump, engineered for reliable and efficient performance. Featuring a polypropylene body and PTFE diaphragms, it is ideal for transferring a wide range of fluids, including chemicals, oils, solvents, and water. Its robust, non-electric design ensures safe operation in demanding environments and with flammable liquids.
- Transfer a wide range of fluids, from water to aggressive chemicals, with its polypropylene body and PTFE diaphragms.
- Operate safely in environments with flammable liquids thanks to its spark-free pneumatic motor.
- Achieve stable, stall-free performance with the 'unbalanced' air valve that prevents operational jamming.
- Handle liquids with small suspended solids up to 2.38mm without damaging the pump.
- Simple installation with standard 1/2" fluid inlet/outlet and 1/4" air inlet connections.
Professional Performance for Fluid Transfer
This air-operated double diaphragm (AODD) pump is the robust and versatile solution for your fluid transfer needs. Made from high-resistance materials, it delivers exceptional performance and a long service life in the toughest conditions. Its pneumatic operation makes it intrinsically safe for use with flammable liquids such as petrol, alcohol, or solvents.
Durable and Corrosion-Resistant Construction
The pump's body is made from polypropylene, a material known for its excellent chemical resistance and toughness. The dual PTFE (Teflon) diaphragms ensure compatibility with a wide variety of aggressive chemicals and prevent premature aging, ensuring a perfect seal and leak-free operation.
Key Technical Specifications
- Body Material: Corrosion-resistant Polypropylene.
- Diaphragms: Dual PTFE for maximum chemical compatibility.
- Connections: 1/2 inch fluid inlet/outlet (12.7mm), 1/4 inch air inlet (6.35mm).
- Max Flow Rate: Up to 8.8 GPM (33.3 L/min).
- Max Head: 226.4 ft (69 metres).
- Suction Lift: Self-priming up to 16.4 ft (5 metres).
- Solids Handling: Passes solids up to 3/32 inch (2.38 mm).
- Max Pressure: 100 psi.
Versatile Applications
- Transfer of waste and new oils.
- Handling of detergents and cleaning agents.
- Pumping solvents, alcohol, petrol, and diesel.
- Transfer of drinking water and other compatible fluids.
Why customers like it
Thanks to its design and materials, this pump is ideal for a multitude of applications in workshops, industry, and agriculture, including:
